END-Armaturen

END-Armaturen Valves

END-Armaturen butterfly, knife-gate, solenoid, check, safety, and motor-driven valves for process and beverage duty.

END-Armaturen Valves

Need END-Armaturen Valves?

Send a part number or nameplate photo. We respond within one business day.

Request a Quote

END-Armaturen offers one of the broadest industrial valve programs available, covering butterfly, knife-gate, solenoid, check, safety, and motor-driven valves, with manual, pneumatic, and electric actuation across water, process, and beverage service.

Representative specs below are for wafer-style butterfly valves; knife-gate, solenoid, and check valves span their own size and pressure ranges. Tell us the media, size, and pressure and we'll match the exact type.

Types & Configurations

  • butterfly
  • knife gate
  • pilot air pressur operated
  • solenoid
  • check valves and strainers
  • safety
  • motor-driven
  • non-return
  • gate
  • spill

Specifications

Nominal size (butterfly)DN40 to DN500
Pressure ratingPN10 / PN16
Max pressureUp to 16 bar (aluminum body); ~6 bar dead-end
Seat/seal materialsEPDM, NBR, PTFE (others on request)
ActuationManual, pneumatic, electric
Pilot pressure (pneumatic)6 bar

Specifications are indicative and vary by model. We confirm exact specs on your quote.

Applications

  • Water & wastewater control
  • HVAC and process piping
  • Chemical & food processing
  • Automated on/off isolation

Example END-Armaturen Valves Part Numbers We Source

A representative, non-comprehensive sample of END-Armaturen Valves part numbers and type codes we source. Don't see yours? Send it over. We source the full catalog.

Part NumberDescription
AC301027Needle valve 1 1/2", female threads, PN120, stainless steel 1.4571/PTFE seals
ADF2D5114032/OSPressure-actuated Valve, DN32, SK63, PN16, Normally Closed
AG111025Ball Valve 1", PN40, Brass, Full Bore
AG111027Ball Valve 1½", PN30, Brass, Full Bore
AM6211075/2-way Solenoid Valve NAMUR DN6 12VDC
AM6212075/2-way Solenoid Valve NAMUR DN6 24VDC
AM6212215/2-way Solenoid Valve 1/4in 24VDC
AM6214075/2-way Solenoid Valve NAMUR DN6 230VAC
AN6212073/2-way NAMUR Solenoid Valve DN6, 24V DC
AN621207/UL3/2-way NAMUR Solenoid Valve DN6, UL Variant
AV301024Needle valve 3/4", PN200, stainless steel/PTFE
AV301025Needle valve, 1", PN200, stainless steel/PTFE
BE121024Angle seat valve 3/4", PN16, brass/NBR-EPDM
BH110027Non-return valve G1-1/2", PN16, brass/PTFE, Y-type
BH120025Non-return valve G1", PN16, brass/EPDM, Y-type
BV311323Mini ball valve 1/2", PN63, stainless steel/PTFE-FKM, internal/external thread
DA2D3115020Pressure actuated valve, DN20, SK50 stainless steel, stainless steel/PTFE, normally closed, with medium
DA2D3131040Pressure actuated valve, DN40, brass/stainless steel/PTFE, normally open
DG2D1221020Pressure actuated valve, G3/4", brass/PTFE-NBR, normally closed
DG2D1224020Pressure-actuated Valve G3/4", SK63 Brass, Against Medium
DG2D1224040Pressure actuated valve, G1 1/2", brass/PTFE-NBR, normally closed
DG2D3118040Pressure-actuated valve, G1-1/2", SK63, stainless steel/PTFE
DG2D3118040/TAPressure actuated valve, G1 1/2", stainless steel/PTFE-fiberglass
DG2D3128025/AXPressure-actuated Valve G1", Stainless Steel, Normally Closed
DG2D3131015Pressure actuated valve, G1/2", brass/stainless steel/PTFE, normally open
DL2D3126025Pressure actuated valve, DN25, stainless steel/PTFE
DL2D3132040/OSPressure actuated valve, DN40, brass/stainless steel/PTFE, normally open
DM2D3129015/OSPressure actuated valve DN15, SK32 stainless steel, stainless steel/PTFE, acting against medium
EB310053Non-return Valve 1/2"-NPT, 600PSI, Stainless Steel
EB310054Non-return Valve 3/4"-NPT, 600PSI, Stainless Steel
EB310055Check valve, 1" NPT, 600PSI, stainless steel/PTFE
EB340026Non-return Valve 1¼", PN40, Stainless steel/EPDM
ED631002Pivoting drive DW100, DIN F07/10, 8kt.17, FKM seal, double-acting, to +140°C
EDV3043Seal kit for ED/EE43
EE631002Pivoting drive EW100, DIN F07/10, 8kt.17, FKM seal, spring return, to +140°C
EZ000001Pressure actuated valve DF2D5123100, DN100, SK125, aluminum/cast iron/PTFE, PN16, normally closed against medium
GZ0000022/2-way solenoid valve, G1/2", brass, 24V DC, PTFE seat seal
IC101030Gate valve 3", PN16, brass
IC101031Gate valve 4", PN16, brass
KA23-ED43/AM24DCBall valve KA, 1/2", with actuator ED43, brass/PTFE-FKM, double-acting
MBMG2Z1214630102/2-way solenoid valve, G3/8", brass/NBR, 110V, force pilot operated
MBMG2Z1216630102/2-way solenoid valve, G3/8"
MBMG2Z1216630152/2-way solenoid valve, G1/2", brass/NBR, 230VAC, 0-10 bar, force pilot, max 90°C
MBMG2Z1222630082/2-way solenoid valve, G1/4", brass/NBR, 24VDC, 0-10 bar, force pilot, max. 90°C
MBMG2Z1222630152/2-way solenoid valve, G1/2", brass/NBR, 24V DC, force pilot operated
MBMG2Z122264025/b2/2-way solenoid valve, G1", brass/NBR, 24V DC, combined operated
MBMG2Z123664025/B2/2-way solenoid valve, G1", brass/NBR, 230V AC, combined operated
MBMG2Z1522630152/2-way solenoid valve, G1/2", brass/HNBR, 24VDC, 0-6 bar, force pilot, max 150°C
MBMG2Z3422630152/2-way solenoid valve, G1/2", stainless steel/EPDM, 0-10 bar, combined operation, -10 to +90°C
MEAG2D3122434202/2-way solenoid valve, G1/4", 24V DC, stainless steel/PTFE, direct-acting
MEAG3D3316434152/2-way solenoid valve, G1/4", 230V AC, stainless steel/PTFE, direct-acting
MEMG2S3342290015/C2/2-way solenoid valve, G1/2", stainless steel/EPDM, 0.5-12 bar, pilot operated, 27VDC, 7.6W
MEMG2S3422290015/C2/2-way solenoid valve, G1/2", stainless steel/EPDM, 0.5-20 bar, pilot operated, 24VDC, 7.6W
MEMG2Z323448025/C2/2-way solenoid valve, G1", stainless steel/NBR, 110V AC, force pilot operated
MGAG2D132243450/LS2/2-way solenoid valve, G1/4", 24V DC, brass/FKM, direct-acting
MGAG2D135682430/AX2/2-way solenoid valve, G1/4", DN3, 230VAC-Ex, brass/FKM, 0-10 bar, ATEX, direct acting
MGAG3D132243420/A3UL3/2-way solenoid valve, G1/4", 24V DC, brass/FKM, direct-acting
MGMG2S122241020/SR2/2-way solenoid valve, G3/4", brass/NBR, 24VDC, 0.3-16 bar, servo-assisted
MGMG2S132243015/OF2/2-way solenoid valve, G1/2", brass/FKM, 24VDC, 0.3-16 bar, servo-assisted
MGMG2S1422430252/2-way solenoid valve, G1", brass/EPDM, 24VDC, 0.3-16 bar, servo-controlled
MGMG2S142245025/NO2/2-way solenoid valve, G1", brass/EPDM, 24VDC, normally open, 0.3-12 bar, servo-assisted
MPV1950001Rexroth 5/2-way valve, 2x24VDC head
MPV1950003Rexroth 3/2-way valve, 24VDC head
MPV2000017Ball valve ZF311025, 1"
MPV2000018Ball valve with actuator
MPV20000192/2-way valve for vacuum and air pressure
MR330021Non-return valve G1/4", PN16, stainless steel/FKM
MR330025Non-return valve G1", PN16, stainless steel/FKM
MR330027Universal check valve 1-1/2", PN16, stainless steel/FKM
MR330031Check valve, 4", PN16, stainless steel/FKM
NG301004Relief valve DN25, input/output with air lever, stainless steel 1.4571
NG301006Relief valve DN40, input/output with air lever, stainless steel 1.4571, set pressure 10 bar
NG301007Relief valve DN50, input/output with air lever, stainless steel 1.4571
NZ000001Spare parts set: seat, cone and seals
ODV3210Spare parts kit for OD/OE210 actuator, FKM seals
RK334007Check valve, DN50, PN40, stainless steel/EPDM
SDF0260.03.0014/P000Seat seal for ADF2D5111020
SDF0270.03.0014/P000Seat seal, G1", PTFE (Fluteck P1050, FDA)
SV130021Safety valve 1/4", free blow-off, brass/FKM
SV210023Safety valve, 1/2" inlet x 1" outlet, red brass/PTFE, 0.5bar set pressure
SV220023Safety valve, G1/2" inlet x G1" outlet, bronze/NBR, 3.0bar set pressure
SV241024Safety valve, 3/4" inlet x 1 1/4" outlet, red brass/NBR, 16bar set pressure
SV242023Safety valve, inlet G1/2 - outlet G1, bronze/EPDM, with bellows, set pressure 6 bar
TA511009Butterfly valve DN80, PN16, length EN558-20, cast iron/PTFE/stainless steel, PTFE-coated
TA531107Butterfly valve DN50, PN16, EN558-20, GGG/PTFE/stainless steel, with hand lever
TA531111Butterfly valve DN125, PN16, length EN558-20, cast iron/PTFE/stainless steel
TA532010Butterfly valve, DN100, PN16, cast iron/stainless steel/NBR
TA532612Butterfly valve, DN150, PN16, ductile iron/stainless steel/NBR
TA532613Butterfly valve, DN200, PN16, ductile iron/stainless steel/NBR
TA532614-SC031022Butterfly valve TA, DN250, with worm gear 90°, GGG/stainless steel/NBR, DVGW-approved
TA533010Butterfly valve, DN100, PN16, cast iron/stainless steel/FKM
TA534010Butterfly valve, DN100, PN16, ductile iron/stainless steel/EPDM
TA552007Butterfly valve, DN50, PN16, ductile iron/steel/NBR
TA552011Butterfly valve DN125, PN16, EN558-20, cast iron/NBR/cast iron
TAH60006Hand lever for butterfly valve, DN40-100, aluminum, 11mm
TB113028Ball valve, 2", PN40, brass/PTFE-FKM, female/female, full bore
TB114324Ball valve 3/4", PN40, brass/PTFE-FKM, female/male thread, full bore, red hand lever
UV310327/AFSpill valve, G1 1/2", medium pressure 2.5-12 bar, PTFE, normally closed by spring, Teflon seat and seals
UV330123Spill valve, G1/2", stainless steel/FKM, medium pressure 0.4-12 bar, spring-to-close
UV330127Overflow valve, G1 1/2", stainless steel/FKM, spring-loaded, normally closed
UV330207Overflow valve, DN50, flanged, stainless steel/FKM, spring-loaded, 0.5-2.5bar
VD311027Ball valve, G1 1/2", PN25, stainless steel/PTFE, female/female, full bore
VDK330X08027Wear part set for piston pressure reducer, G1 1/4"+1 1/2", FKM, piston Ø 80mm
VDX2D3113080Wear parts set, G3"-DN80, PTFE, SK125, for DL2D3123080/OS and DL2D3133080/OS
VDX2D3122025Wear and tear set, G1, PTFE, SK80 brass
VDX2D3131025Sealing kit, G1", PTFE, SK50, RAGM
VDX2D3132040Sealing set, G1-1/2"-DN40, PTFE, SK80
VH311421Ball valve G1/4", PN140, polished stainless steel/PTFE, full bore
VHD10125Sealing kit for VH3100 valve, 1", PTFE
VK311006-EE620852Ball valve, DN40, with actuator, stainless steel/PTFE-FKM, spring return
VK451007/METWafer-type ball valve DN50, PN16, steel/PTFE-metal-FKM/stainless steel, antistatic, max. 10 bar, max. 180°C
VK451010-ED621002Ball valve VK, DN100, with actuator ED, DW100, steel/PTFE-FKM, double-acting
VK461010Wafer-type ball valve, DN100, PN16, carbon steel/PTFE-FKM/chrome-plated brass
VN111424-ED620552Ball valve VN, 3/4", with actuator, brass/PTFE-FKM, L-bore, double-acting
WAWafer-type Butterfly Valve
WA334010Butterfly valve, DN100, PN10/16, stainless steel/EPDM, ISO 5211
WA334011Butterfly valve, DN125, PN10/16, stainless steel/EPDM
WA534010-EE621002Butterfly valve WA, DN100, with actuator, cast iron/stainless steel/EPDM, spring return
WC333007Wafer check valve DN50, PN10/PN16, stainless steel/FKM
WGE-GG-MET-050/PDKnife gate valve, GG25/metal, DN50, PN10, GG25/stainless steel, double-acting
WGE-GG-NBR-100/PDKnife gate valve, GG25/stainless steel/NBR, DN100, PN10, double-acting
WGE-GG-NBR-150/MWKnife gate valve, DN150, PN10, cast iron/stainless steel/NBR, non-rising stem
WGE-GG-NBR-200/MWKnife gate valve, DN200, PN8, cast iron/stainless steel/NBR, non-rising stem
WGS-SE-NBR-100Seat seal, NBR, for knife-gate valve DN100
WGS-SE-NBR-200Seat seal, NBR, for knife-gate valve DN200
WGSB-SE-EPDM-300Seat seal, EPDM, for knife-gate valve DN300, bidirectional
WMLUG-type Butterfly Valve
WOS-SE-EPDM-500Seat seal, EPDM, for knife-gate valve DN500
XDG2D3125020/A28Pressure actuated valve, G3/4", SK50 stainless steel, OG-OS, stainless steel/PTFE
XDG2D3921015/A01Pressure-controlled valve, G1/2", SK50 brass, stainless steel/EPDM-PTFE, 6 bar control pressure
ZA25-EE63Ball valve ZA, 1" internal thread, with actuator EE63, stainless steel/PTFE-FKM, spring return
ZA62-EE55Ball valve ZA, DN15, welding end, with actuator EE55, stainless steel/PTFE-FKM, spring return
ZA66-EE85Ball valve ZA, DN40, welding end, with actuator EE85, stainless steel/PTFE-FKM, spring return
ZA310023-NE054100Ball valve ZA, 1/2" internal thread, with actuator NE05, stainless steel/PTFE-FKM, 230V 50Hz, running time 14 sec
ZA310362-EE620632Ball valve, DN15 welding end, with EE63 actuator, stainless steel/PTFE-FKM, low-cavity, spring return
ZAD10024Seal Kit ZA, 3/4"-DN20, PTFE/FKM
ZAH30030Hand lever set for ZA 1-1/2" and 2" valves
ZDD13002Seal Kit ZD, DN15, PTFE/FKM
ZE311026Ball valve 1-1/4", PN40, stainless steel/PTFE, female, full bore, DIN3202-M3
ZE311058Valve
ZE311064/HTBall valve, DN25, PN64, stainless steel/PTFE, high-temperature, butt-welded, full bore
ZE311065Ball valve DN32, PN40, stainless steel/PTFE, weld ends, full bore, DIN3202-S13
ZED10029Seal kit for ZE, 2-1/2"/DN65, PTFE
ZED10030Seal kit for ZE ball valve, 3"/DN80, PTFE
ZED10031Sealing kit for ZE ball valve, 4"/DN100, PTFE
ZH311025Ball valve, 1", PN100, stainless steel/PTFE-GF, female thread, full bore, ISO 5211
ZL311021Ball valve 1/4", PN64, stainless steel/PTFE, 2-piece, female thread, full bore
ZL311026Ball valve 1-1/4", PN40, stainless steel/PTFE, 2-piece, female thread, full bore
ZL311029Ball valve 2 1/2", PN40, 1.4408/PTFE, 2-piece, female thread, full bore
ZL311053Ball valve 1/2" NPT, 1000 WOG, 1.4408/PTFE, 2-piece, female, full bore
ZL312321Ball valve 1/4", PN64, stainless steel/PTFE, butterfly handle, 2-piece, full bore
ZP311006Ball valve, DN40, PN16/40, full bore, stainless steel/PTFE-FKM, ISO 5211
ZR330004Non-return valve, wafer type, DN25, PN6-40, stainless steel, max 40 bar
ZR330009Wafer-type check valve, DN80, PN6-40, stainless steel
ZU310024-ED620432Ball valve TO, 3/4", with actuator, stainless steel/PTFE-FKM, double-acting

END-Armaturen Valves: Common Questions

Flanged ball valves run DN10 to DN300, with threaded and welded versions from 1/4 inch to 6 inch. The standard body is stainless steel 1.4408 with PTFE ball seals. The wider program reaches DN4 to DN1000.

Ball valves suit tight shutoff and frequent cycling on smaller lines; butterfly valves suit larger diameters where weight and cost matter more than absolute sealing. Tell us the line size, medium and duty.

Yes. Actuated assemblies are supplied with pneumatic or electric actuators fitted and matched, rather than as loose parts to pair up on site.

The part number if you have it. Otherwise the line size, pressure rating, medium, end connection, body and seat material, and whether it is manual or actuated.

Yes, along with mating flanges and handles, so an installed valve stays serviceable rather than being replaced whole.

More From END-Armaturen

END-Armaturen Actuators

Actuators

END-Armaturen actuators drive its butterfly and ball valve lines, with pneumatic part-turn actuators (in-house-developed and lower-cost economy lines) and electric.

Details & quote
END-Armaturen Brewing Equipment

Brewing Equipment

END-Armaturen doesn't sell a separate "brewing" product line.

Details & quote
END-Armaturen Flanges

Flanges

END-Armaturen's flange and fitting program covers the connection hardware around its valve line, including threaded, coupling, and hose fittings for pipework.

Details & quote

All Valves & Seals Manufacturers
